中文简体In the field of industrial automation and precision measurement, the pressure gauge connector is an important component connecting the pressure gauge and the pipeline system. Its performance and reliability directly affect the stable operation of the entire system. The 7BC-GDK MAVE pressure gauge connector, with its unique structural design and excellent sealing performance, has become an indispensable connection component in many industrial equipment.
The 7BC-GDK MAVE pressure gauge connector is a connector designed for industrial pressure measurement systems. One end adopts a 24° cone design and the other end is a standard thread interface, suitable for metric and imperial systems. The product is equipped with an O-ring seal (ISO8434 DIN2353) and can be equipped with steel or copper gaskets to ensure sealing and leakproof performance under various working conditions.
Structural features
The connector adopts a 24° cone design, complies with ISO8434 and DIN2353 standards, and is suitable for a variety of pressure gauge systems. Its female end is equipped with steel or copper gaskets to adapt to different materials and pressure requirements to ensure the sealing and stability of the connection. In addition, the product also supports a variety of connection methods, including a rotating connection nut design, which is convenient for adjusting the connection direction and reducing the difficulty of assembly and disassembly.
Material and sealing
7BC-GDK MAVE pressure gauge connectors are usually made of stainless steel or carbon steel and are suitable for high-pressure environments. Its sealing method is O-ring sealing to ensure that there is no leakage at the connection, which is suitable for hydraulic systems, pneumatic systems and industrial measurement equipment. In addition, the product also supports a variety of sealing materials, such as DKI sealing rings, O-rings, etc., to meet the needs of different application scenarios.
Application field
7BC-GDK MAVE pressure gauge connectors are widely used in many industrial fields due to their unique structural design and excellent sealing performance. The connector has a 24° cone on one end and a standard threaded interface on the other end. It is suitable for metric and imperial systems and can be flexibly adapted to a variety of pressure gauges and pipeline systems. Its O-ring seals (ISO8434 DIN2353) and optional steel or copper gaskets ensure sealing and stability in high pressure, high temperature or corrosive environments.
1. In the field of industrial automation, this connector is often used to connect pressure gauges to hydraulic or pneumatic systems to achieve accurate measurement and control of pressure. Its rotating connection nut design facilitates frequent disassembly and adjustment, and is suitable for industrial equipment that requires frequent maintenance or commissioning. In addition, the connector also supports non-standard customization to meet the connection requirements under special working conditions.
2. In the field of marine machinery, the 7BC-GDK MAVE pressure gauge connector is widely used in the installation of hydraulic systems, pneumatic systems and pressure gauges of ships due to its pressure resistance and sealing performance. Its structural design enables it to adapt to the complex environmental conditions of ships, such as salt spray, vibration and temperature changes.
3. In the oil and gas industry, this connector is used to connect pressure gauges to pipeline systems to ensure stable operation under high pressure, high temperature and corrosive media. Its structural design enables it to adapt to the pressure measurement needs in complex environments such as oil fields and refineries.
4. In the chemical industry, the connector is used to connect the pressure gauge to the pipeline system to ensure the sealing and safety under chemical media (such as acids, alkalis, solvents, etc.). Its structural design enables it to adapt to various pressure measurement needs in chemical production.
5. In the power industry, the connector is used to connect the pressure gauge to the pipeline system of equipment such as boilers and steam turbines to ensure stable operation under high temperature and high pressure environments.
6. In the pharmaceutical and food processing industries, the connector is used to connect the pressure gauge to the pipeline system to ensure hygiene and safety in the production process of food and medicine. Its structural design enables it to adapt to the cleaning and disinfection requirements in food and drug production.
7. In the laboratory and scientific research field, the connector is used to connect the pressure gauge to the experimental equipment to ensure accuracy and stability in precision measurement. Its structural design enables it to adapt to various pressure measurement needs in the laboratory.
Product Advantages
The advantage of the 7BC-GDK MAVE pressure gauge connector is its low torque fixing process, which is easy to assemble and disassemble, and has good adaptability to pressure fluctuations and vibrations in the system. In addition, the product supports customized production and can provide non-standard products to meet special needs. Its structural design not only improves the reliability of the connection, but also improves the efficiency and safety of the overall system.
Related accessories
The product can be equipped with a variety of accessories, such as nuts, ferrules, etc., to complete the assembly structure. In addition, a variety of sealing materials, such as DKI sealing rings, O-rings, etc., are also provided to meet the needs of different application scenarios. The flexible combination of these accessories makes the 7BC-GDK MAVE pressure gauge connector more flexible and adaptable in practical applications.
Product standards and certifications
The 7BC-GDK MAVE pressure gauge connector complies with international standards such as ISO8434, DIN2353, DIN3858, and is suitable for a variety of pressure levels. Please refer to the product manual for specific pressure values.
Product illustrations and installation instructions
The product provides detailed illustrations showing the connection method of the 24° cone and the threaded interface. The installation instructions include seal installation, gasket selection and connection steps, so that users can quickly master the installation method. In addition, users can also refer to the product manual or technical documents for detailed installation instructions.
Product Maintenance and Care
To ensure the long-term stable operation of the 7BC-GDK MAVE pressure gauge connector, it is recommended to regularly check the wear of the seal and gasket and replace damaged parts in time. At the same time, clean the connection parts to prevent impurities from entering the system to extend the service life.
The 7BC-GDK MAVE pressure gauge connector has become a key component in industrial measurement systems due to its excellent structural design, reliable sealing performance and wide range of applications. Whether in terms of product performance or market application, this product has demonstrated its core value in the field of industrial automation.
