| Product Standards: | DIN2353/ISO8434 |
| Product Materials: | Carbon steel/stainless steel |
| Surface finish: | White zinc/zinc-nickel alloy |
| Thread: | NPT SAE BSP ORFS metric thread |
| Product Features: | Sealing is achieved by means of a 90° tapered spool and a synthetic sealing ring in conjunction with a tapered seat, the spool opening is positioned so that it opens reliably, with low vibration and low noise levels. |
| Application areas: | Hydraulic systems are particularly suitable for construction, agricultural, mining and painting machinery, but also for steam and oil and gas media (but please note the choice of sealing material) |
|
Series
|
D1
|
T1
|
CFDN
|
71DN
|
D3
|
CFL1
|
71
L1
|
L2
|
L3
|
L4
|
S1
|
CF
S2
|
71
S2
|
S3
|
Weight
g/piece
|
Order number
|
Working pressure (bar)
|
|
|
CF
|
71
|
|||||||||||||||||
|
L
|
06
08
10
12
15
|
G 1/8A
G 1 1/4A
G 1 1/4A
G 3/8A
G 1/2A
|
3.5
5.5
7.5
9.5
11.0
|
3.5
5.5
7.5
9.5
11.5
|
14
19
19
22
27
|
35.0
37.0
46.0
50.0
53.0
|
35.0
37.0
45.5
49.5
52.5
|
28.0
30.0
38.5
42.5
45.5
|
8
12
12
12
14
|
42.5
44.5
53.0
57.0
60.5
|
17
19
22
27
27
|
17
19
24
30
32
|
17
19
24
30
32
|
14
17
19
22
27
|
47
62
105
175
205
|
RHV06LREDOMD
RHV08LREDOMD
RHV10LREDOMD
RHV12LREDOMD
RHV15LREDOMD
|
400
400
400
400
400
|
250
250
250
250
250
|
|
18
22
28
35
42
|
G 1/2A
G 3 1/4 A
G 1A
G 1 1/4A
G 1 1/2A
|
14.0
18.0
23.0
29.0
29.0
|
14.0
18.0
23.0
29.0
29.0
|
27
32
40
50
55
|
58.0
63.0
71.0
80.0
80.0
|
57.5
62.5
70.5
79.5
79.5
|
50.0
55.0
63.0
69.0
68.5
|
14
16
18
20
22
|
66.0
71.0
79.5
90.0
91.0
|
36
41
50
60
65
|
41
46
55
65
70
|
36
46
55
60
70
|
32
36
41
50
60
|
294
450
720
1050
1560
|
RHV18LREDOMD
RHV22LREDOMD
RHV28LREDOMD
RHV35LREDOMD
RHV42LREDOMD
|
400
250
250
250
250
|
160
160
100
100
100
|
|
|
S
|
06
08
10
12
14
|
G 1 1/4A
G 1 1/4A
G 3/8A
G 3/8A
G 1/2A
|
3.5
3.5
5.5
7.5
9.5
|
3.5
3.5
5.5
7.5
9.5
|
19
19
22
22
27
|
38.5
38.5
45.5
48.5
53.0
|
38.5
38.5
45.5
48.5
52.5
|
31.5
31.5
38.0
41.0
44.5
|
12
12
12
12
14
|
46.0
46.0
54.0
57.0
62.0
|
19
19
22
24
27
|
19
19
24
27
32
|
19
19
24
27
32
|
17
19
22
24
27
|
73
79
132
153
230
|
RHV06SREDOMD
RHV08SREDOMD
RHV10SREDOMD
RHV12SREDOMD
RHV14SREDOMD
|
420
420
420
420
420
|
400
400
400
400
315
|
|
16
20
25
30
38
|
G 1/2A
G 3/4A
G 1A
G 1 1/4A
G 1 1/2A
|
11.0
15.0
19.0
24.0
29.0
|
11.5
15.0
19.0
24.0
29.0
|
27
32
40
50
55
|
57.0
63.0
-
78.0
86.0
|
56.5
62.5
66.5
77.5
85.5
|
48.0
52.0
54.0
64.0
69.5
|
14
16
18
20
22
|
66.0
73.5
78.5
90.0
100.0
|
32
41
46
60
65
|
36
50
55
60
70
|
36
46
50
60
70
|
30
36
46
50
60
|
293
511
648
1176
1624
|
RHV16SREDOMD
RHV20SREDOMD
RHV25SREDOMD
RHV30SREDOMD
RHV38SREDOMD
|
420
420
420
250
250
|
315
250
250
250
250
|
|
